New arrival 230*230*260mm dual Z axis synchronous belt free leveling Magician X 3D Drucker 3d printer with tmc2208

SPECIFICATIONSYear: 2021Weight: 12 KGWarranty of core components: 1 YearWarranty: 1 YearVoltage: 110V/220VVideo outgoing-inspection: ProvidedUsage: Bill Printer, Card Printer, Paper Printer, Tube Printer, 3D PrinterTechnology: FDMProduction Capacity: 2000pcs/MonthProduct name: Magician X free leveling 3D PrinterPrinting size: 230*230*260mmPrint speed: 0-100mm/sPlace of Origin: Guangdong, ChinaOrigin: Mainland ChinaNozzle: Standard 0.4 mmMolding Technology: FDMMaterial: PLA/ABS/TPU...
Title :
-
+
$1,577.60

0

9 In Stock

SPECIFICATIONS

Year: 2021

Weight: 12 KG

Warranty of core components: 1 Year

Warranty: 1 Year

Voltage: 110V/220V

Video outgoing-inspection: Provided

Usage: Bill Printer, Card Printer, Paper Printer, Tube Printer, 3D Printer

Technology: FDM

Production Capacity: 2000pcs/Month

Product name: Magician X free leveling 3D Printer

Printing size: 230*230*260mm

Print speed: 0-100mm/s

Place of Origin: Guangdong, China

Origin: Mainland China

Nozzle: Standard 0.4 mm

Molding Technology: FDM

Material: PLA/ABS/TPU etc

Machinery Test Report: Provided

Layer Thickness: 0.05-0.3mm

Key Selling Points: Easy to Operate

Forming size: 230*230*260mm

Filament Diameter: 1.75mm

Features: High Resolution free leveling 3D Printer

Extruder Number: standard single

Dimension(L*W*H): 230*230*260mm

Core Components: Motherboard

Condition: New

Color & Page: single color

Brand Name: MINGDA 3D Printer

Brand Name: Vieruodis

Automatic Grade: Automatic

Application: 3d model making, 3D model printing

Products Descripition
Magician X FDM 3D Printer: Innovator of Auto-Leveling
MINGDA Magician X--An amazing modular FDM 3D Printer unleashes your 3D printing potential! Equipped with a new 32-bit motherboard and a high-performance ST-407 architecture main control chip, MINGDA features faster computing speed and smoother system. The integration of TMC2209 silent driver makes the motherboard have both silent printing and precise voltage output control, which ensures a more accurate and silent printing.

Technical Specifications

● Print parameters: FDM ( Fused Deposition Modeling)
● Build Volume: 230(L)*230(W)*260(H)mm
● Print Resolution: ± 0.1mm
● Positioning Accuracy: X/Y 0.0125mm, Z 0.002mm
● Nozzle Diameter: 0.4mm
● Print Speed: <200mm/s (recommended 60 - 80mm/s)
● Support Filaments: PLA, TPU, ABS
● Software parameters: Cura
● Formats: .STL .Gcode
● Connection Mode: SD Card, U Disk, USB-C
● Input voltage: 100/240 V AC, 60/50Hz
● Output voltage: 24V/14.6A (350W)
● Operational Nozzle Temperature: max ≤260℃
● Operational Hot Bed Temperature: max ≤110℃
● Machine Size: 460mm*415mm*546mm
● Machine Weight: ~7.4kg











Details Images
Auto Leveling Don't need manual leveling, the intelligent leveling system can automatically adjust the uneven hotbed.High-sensitivity sensor,
16-point precise leveling.
Ready to Print
One step assemble, ready to print
Ultra-Silent Printing
Ultra-quiet mechanical structure

Glass Heat Bed

The 4th generation of glass heat bed cold glue installation,easy to take the model and scratch proof.

Dual Cooling Fans

The printing head adopts a double fan two-way heat dissipation system, cools down models rapidly. The printing speed is faster

Double Gears Direct Extrusion

Conveying material uniform without winding

Automatic Filament Detection

Broken material can be automatically detected

Multi Connection

Support SD card, USB and USB-C, supports online printing

Dual Z-Axis with Synchronous Belt

Improve the accuracy, keep the "layer shift" away.

Belt Tensioner on X/Y Axis

Adjust the belt tightness to avoid long-term use of the printer, the belt is loose.

Filament Holder

Can be flexibly assembled on the left and right sides

Build-in Tool Box

Convenient after using the tool

3.5" colorful touch screen

The screen adopts a new UI interface, manipulate photos, and switch in multiple languages. New interface; large screen; simple operation.

Stepping Drive - Ultra Quiet TMC

Use TMC 2209 Stepper Motor Drivers,Super Quiet and Noise Reduction,running more stable,≤50dB silent printing

Brand core :Imported control chip exceed expectations

Imported control chip; high-speed computing; high-performance, high-end chips, 32-bit frequency: 168M;
Company Profile

Shenzhen Mingda Technology Co., Ltd

has more than 12 years of manufacturing and design experience for 3D printers. We specialize in researching and production of 3D printers and 3D filaments. We have professional R&D team, domestic advanced production equipment and precision instruments. Quality Guarantee is always our aim. We have proven to be a dependable, trustworthy, engaged and efficient company that always adheres to increase customers' satisfaction.All our products have pass CE,FCC,ROHS, ISO9001 certificates.

We focus on professional industrial 3d printer MD 4H / 6H/ 600/1000 , newest DIY 3d printer,and LCD 3D Printer, print size from 119*160*67mm to 1000*1000*1000mm which will extend your profile and profit, So I think our possibility of  cooperation definitely exist. Let us work together to open up new prospects for win-win cooperation!



Our Services & Strength

1. One year warranty and lifetime technical support.

2. MINGDA has exclusive services for every customer who purchase MINGDA 3D printer. Please feel free to contact with our after-sales service staff anytime you need help, we will try our best to help you with the solution.
3. Our customers will get the professional and complete operating guide and operating videos.

Now we are looking for distributor of Magician X
Welcome to send us inquiry and to be our resellers!
